Brand Name : HAFE
Model Number : MH50-MH1500
Certification : CE
Place of Origin : China
MOQ : 1unit
Price : Negotiable
Payment Terms : T/T
Supply Ability : 3000units/year
Delivery Time : 5-8working day
Packaging Details : Export Carton Packing
Standard : USA standard
Type : Metal Hailde Lamps
Walt : 50-1500W
Avg.Life : 15000V/10000H
Lamp Color : white- warm White
lamp Color : 3200k-4200k
Usage : Street Road Lighting
50W -1500W USA standard Metal Hailde Lamps 100W 250W Street Road Lighting
The lamps consist of a small fused quartz or ceramic arc tube which contains the gases and the arc, enclosed inside a larger glass bulb which has a coating to filter out the ultraviolet light produced. They operate at a pressure between 4 and 20 atmospheres, and require special fixtures to operate safely, as well as an electrical ballast. Metal atoms produce most of the light output. They require a warm-up period of several minutes to reach full light output.
Metal-halide lamps are used for general lighting purposes both indoors and outdoors, such as commercial, industrial, and public spaces, parking lots, sports arenas, factories, and retail stores, as well as residential security lighting; automotive and specialty applications are further fields of usage.
Lumens | Dimensions | Color | Case | |||||||||
Watts | Bulb | Description | ANSI | Initial | Mean | Mol | LCL | Avg.Life | Temp | CRI | Finish | Qty |
(lm) | (lm) | (in) | (in) | (Hours) | ||||||||
Metal Hailde Lamps-MHEDium Screw Base | ||||||||||||
50 | HED17 | MH50/HED17/U/4K | M110/E | 3400 | 2200 | 5.44 | 3.38 | 10000V/7500H | 4200 | 65 | Clear | 12 |
50 | HED17 | MH50/HED17/C/U/4K | M110/E | 3200 | 2100 | 5.44 | 3.38 | 10000V/7500H | 4000 | 70 | CoatHED | 12 |
70 | HED17 | MH70/HED17/U/3K | M98/E | 5600 | 3600 | 5.44 | 3.38 | 15000V/10000H | 3200 | 65 | Clear | 12 |
70 | HED17 | MH70/HED17/C/U/3K | M98/E | 5300 | 3400 | 5.44 | 3.38 | 15000V/10000H | 3200 | 70 | CoatHED | 12 |
70 | HED17 | MH70/HED17/U/4K | M98/E | 5600 | 3600 | 5.44 | 3.38 | 15000V/10000H | 4200 | 65 | Clear | 12 |
70 | HED17 | MH70/HED17/C/U/4K | M98/E | 5300 | 3400 | 5.44 | 3.38 | 15000V/10000H | 4000 | 70 | CoatHED | 12 |
70 | HED17 | MH70/HED17/U/4K | M98/E | 5600 | 3600 | 5.44 | 3.38 | 15000V/10000H | 4200 | 65 | Clear | 12 |
100 | HED17 | MH100/HED17/C/U/4K | M90/E | 8500 | 5500 | 5.44 | 3.38 | 15000V/10000H | 4000 | 70 | CoatHED | 12 |
100 | HED17 | MH100/HED17/U/3K | M90/E | 9000 | 5900 | 5.44 | 3.38 | 15000V/10000H | 3200 | 65 | Clear | 12 |
100 | HED17 | MH100/HED17/C/U/3K | M90/E | 8500 | 5500 | 5.44 | 3.38 | 15000V/10000H | 3200 | 70 | CoatHED | 12 |
100 | HED17 | MH100/HED17/U/4K | M90/E | 9000 | 5900 | 5.44 | 3.38 | 15000V/10000H | 4200 | 65 | Clear | 12 |
150 | HED17 | MH150/HED17/U/4K | M102/E | 14000 | 10500 | 5.44 | 3.38 | 15000V/10000H | 4200 | 65 | Clear | 12 |
150 | HED17 | MH150/HED17/C/U/4K | M102/E | 13300 | 10000 | 5.44 | 3.38 | 15000V/10000H | 4000 | 70 | CoatHED | 12 |
175 | HED17 | MH175/HED17/U/4K | M57/E | 17500 | 12800 | 5.44 | 3.38 | 10000V/7500H | 4200 | 65 | Clear | 12 |
175 | HED17 | MH175/HED17/C/U/4K | M57/E | 16600 | 12500 | 5.44 | 3.38 | 10000V/7500H | 4000 | 70 | CoatHED | 12 |
![]() |
50 - 1500 Watt Metal Hailde Lamps Warm White Street Road Lighting 15000 V / 10000 H Images |
